**VBAChromeDevProtocol** VBAChromeDevProtocol is a set of Visual Basic for Applications (VBA) source files to allow controlling Chrome, Edge (and to a limited extent, Firefox) by using the browser's Chrome Developer Protocol. This can be used to automate various tasks with browser. Normally Selenium, Puppeteer, or Playwright should be used as these are mature software with a community to back them. However, if you are unable to install additional software or simply want a self contained solution that doesn't require the user to install additional software then this can be an option. This is primarily tested using Excel, but should be compatible with other applications such as Access or Outlook which also support VBA. Quick Start =============================================================================== The basics, e.g. launch Google's site ------------------------------------------------------------------------------- To use, within a Sub in a VBA module create an AutomateBrowser object, launch the browser to the desired page to navigate to, and then quit the browser. ``` Sub demo() Dim browser As AutomateBrowser Set browser = new_automateBrowser browser.launch "https://www.google.com/" Debug.Print JsonConverter.ConvertToJson(browser.cdp.browser.getWindowForTarget) browser.Quit End Sub ``` License ------------------------------------------------------------------------------- Primarily licensed under MIT terms, however, uses existing projects and samples which are licensed under [MIT](https://opensource.org/licenses/MIT), [The Code Project Open License / CPOL](http://www.codeproject.com/info/cpol10.aspx), [Creative Commons license / stack overflow](https://creativecommons.org/licenses/by-sa/4.0/) and [Microsoft documentation terms](https://docs.microsoft.com/en-us/legal/termsofuse) Tutorials =============================================================================== Setup ------------------------------------------------------------------------------- - create a new document (e.g. in Excel, new document), for browser control - in the VBA editor (development tools) copy the source modules from [here](https://github.com/PerditionC/VBAChromeDevProtocol/). Be sure to copy all the files in src/ directory and needed ones from src/cdp/ *(The files in generator are only used to create the files in src/cdp/ and the files in src/examples are not needed normally.)* * Either do the long and arduous task of _Importing File..._ for each of the source files or * Open the src directory in Windows Explorer and drag the files to the VBA modules' window in Excel ![highlight & drag-n-drop source files to VBA Project window, modules section](dnd-files.png) - add a reference to Microsoft Scripting Runtime *needed for Dictionary* (Optionally and unsupported, use alternative Dictionary class - see https://github.com/VBA-tools/VBA-Dictionary) ![add reference to scrrun.dll](scrrun.jpg) - **save** document as addin (or macro enabled file), e.g. as "CDP Addin.xlam" - create another document, this will be your project! - add a reference to previously created file, e.g. to "CDP Addin.xlam" > 📃 **Note:** Source files need to have DOS/Windows [\r\n] line endings > or VBA will import class modules incorrectly as modules > (i.e. if files have only \n line endings, import will fail) > 📃 **Note:** Or use the "CDP Addings.xlam" included in the distribution > instead of recreating it. Basic Example ------------------------------------------------------------------------------- ### Minimal Minimally, you need to create an instance of the AutomateBrowser (or clsCDP) class and launch the browser to desired web page. Optionally, close the browser. ``` vbs Sub Ex_Minimal() ' create an instance to our AutomateBrowser class ' the module this subroutine is created in must have a reference to the ' document with the VBAChromeDevProtocol source files imported into. Dim browser As AutomateBrowser Set browser = new_automateBrowser ' start up the browser, which ever one first found of Edge, Chrome, Firefox ' and pass it the command line option to load our web page on startup. browser.launch "https://www.google.com/" ' optionally close the browser once done 'browser.Quit End Sub ``` ### Simple Interaction ``` vb Sub Google_search() ' common setup, create browser class and spawn browser Dim b As AutomateBrowser: Set b = new_automateBrowser b.launch b.navigate "https://www.google.com" 'find node by class Dim SearchBar As cdpDOMNode Set SearchBar = b.querySelector(".gLFyf.gsfi") 'do something to/with the node; i like having the methods here vs by b.method node.nodeId, etc SearchBar.elementAttribute("value") = "cats" sleep 1 SearchBar.elementAttribute("value") = "" sleep 1 SearchBar.elementValue = "big cats" ' print out some of its properties Debug.Print SearchBar.innerText Debug.Print SearchBar.Title Debug.Print SearchBar.Value Debug.Print SearchBar.elementValue sleep 1 Dim myInputs As Dictionary Dim myInput As cdpDOMNode 'find nodes by tag Set myInputs = b.querySelectorAll("input[class~='gLFyf'][class~='gsfi']") Set myInput = myInputs.Items(0) myInput.SetValue "tiger", SNV_FakeInput sleep 1 myInput.SetValue "lion", SNV_Clipboard ' clear popup list b.cdp.SimulateInput.dispatchKeyEvent "keyDown", code:="Escape", windowsVirtualKeyCode:=27 b.cdp.SimulateInput.dispatchKeyEvent "keyUp" 'find a node by class name 'Set myInputs = b.getNodesByClassName("gLFyf gsfi") 'Set myInput = myInputs.Items(0) myInput.elementValue = "baby cats" Debug.Print myInput.elementValue sleep 1 'loop through nodes to find a specific node Dim v As Variant For Each v In myInputs.Items Set myInput = v If myInput.elementAttribute("class") = "gLFyf gsfi" Then myInput.SetValue "kittens" Exit For End If Next v ' clear popup list sleep 1 ' needed before we press escape to give time for popup to pop up b.cdp.SimulateInput.dispatchKeyEvent "keyDown", code:="Escape", windowsVirtualKeyCode:=27 b.cdp.SimulateInput.dispatchKeyEvent "keyUp" 'find node by exact selector path as copied from debugger Dim SearchButton As cdpDOMNode Set SearchButton = b.querySelector("body > div.L3eUgb > div.o3j99.ikrT4e.om7nvf > form > div:nth-child(1) > div.A8SBwf > div.FPdoLc.lJ9FBc > center > input.gNO89b") SearchButton.Click sleep 1 b.alert "weeee it worked. click 'ok' to close" b.Quit End Sub ``` Reference (API) =============================================================================== AutomateBrowser ------------------------------------------------------------------------------- clsCDP ------------------------------------------------------------------------------- Facades ( examples from similar tools) =============================================================================== Pupeeter ------------------------------------------------------------------------------- ### Example for comparison From https://hacks.mozilla.org/2021/01/improving-cross-browser-testing-part-2-new-automation-features-in-firefox-nightly/ and https://github.com/puppeteer/puppeteer/blob/main/examples/cross-browser.js #### Original An example (in javascript) launching firefox from puppeteer and getting an element: ``` javascript const puppeteer = require('puppeteer'); (async () => { const browser = await puppeteer.launch({ product: 'firefox', }); const page = await browser.newPage(); console.log(await browser.version()); await page.goto('https://news.ycombinator.com/'); // Extract articles from the page. const resultsSelector = '.titlelink'; const links = await page.evaluate(resultsSelector => { const anchors = Array.from(document.querySelectorAll(resultsSelector)); return anchors.map(anchor => { const title = anchor.textContent.trim(); return `${title} - ${anchor.href}`; }); }, resultsSelector); console.log(links.join('\n')); await browser.close(); })(); ``` #### Equivalent And the same example using VBAChromeDevProtocol (in VBA): ``` vb Sub Puppeteer_Example() Dim v As Variant ' const puppeteer = require('puppeteer'); ' ' (async () => { ' const browser = await puppeteer.launch({ ' product: 'firefox', ' }); ' const page = await browser.newPage(); Dim browser As AutomateBrowser: Set browser = new_AutomateBrowser ' !!! firefox not yet working, use Edge or Chrome ' browser.launch whichBrowser:=firefox, useWebSocket:=True browser.launch whichBrowser:=Chromium ' console.log(await browser.version()); Dim versionInfo As Dictionary Set versionInfo = browser.cdp.browser.getVersion For Each v In versionInfo.Keys Debug.Print v & " : " & versionInfo(v) Next v ' await page.goto('https://news.ycombinator.com/'); browser.navigate "https://news.ycombinator.com/" ' // Extract articles from the page. ' const resultsSelector = '.titlelink'; Const resultsSelector = ".titlelink" ' const links = await page.evaluate(resultsSelector => { Dim links() As String ' const anchors = Array.from(document.querySelectorAll(resultsSelector)); Dim anchors As Dictionary Set anchors = browser.querySelectorAll(resultsSelector) ' return anchors.map(anchor => { ' const title = anchor.textContent.trim(); ' return `${title} - ${anchor.href}`; ' }); ' }, resultsSelector); Dim linkCount As Long: linkCount = 0 For Each v In anchors.Items Dim anchor As cdpDOMNode: Set anchor = v Dim title As String: title = Trim(anchor.textContent) ReDim Preserve links(linkCount) As String links(linkCount) = title & " - " & anchor.getPropertyValue("href") linkCount = linkCount + 1 Next v ' console.log(links.join('\n')); Debug.Print Join(links, vbNewLine) ' await browser.close(); ' })(); browser.Quit End Sub ``` #### Alternative Or same example but like original executing logic in browser context ``` vb Sub Puppeteer_Example_Evaluate() Dim v As Variant ' const puppeteer = require('puppeteer'); ' ' (async () => { ' const browser = await puppeteer.launch({ ' product: 'firefox', ' }); ' const page = await browser.newPage(); Dim browser As AutomateBrowser: Set browser = new_AutomateBrowser 'browser.launch whichBrowser:=firefox, useWebSocket:=True browser.launch whichBrowser:=Chromium ' console.log(await browser.version()); Dim versionInfo As Dictionary Set versionInfo = browser.cdp.browser.getVersion For Each v In versionInfo.Keys Debug.Print v & " : " & versionInfo(v) Next v ' await page.goto('https://news.ycombinator.com/'); browser.navigate "https://news.ycombinator.com/" ' // Extract articles from the page. ' const resultsSelector = '.titlelink'; Const resultsSelector = "'.titlelink'" ' const links = await page.evaluate(resultsSelector => { ' const anchors = Array.from(document.querySelectorAll(resultsSelector)); ' return anchors.map(anchor => { ' const title = anchor.textContent.trim(); ' return `${title} - ${anchor.href}`; ' }); ' }, resultsSelector); Dim js As String js = "resultsSelector => { " & _ " const anchors = Array.from(document.querySelectorAll(resultsSelector));" & _ " return anchors.map(anchor => {" & _ " const title = anchor.textContent.trim();" & _ " return `${title} - ${anchor.href}`;" & _ " });" & _ "}" Dim links As String links = browser.jsEval("(" & js & ")(" & resultsSelector & ").join('\n');") ' console.log(links.join('\n')); Debug.Print links ' await browser.close(); ' })(); browser.Quit End Sub ``` ### Chrome Replay export See Puppeteer.xlsm source for implementation. From Chrome record your actions and then export the JSON version (not direct Puppeteer javascript). Then load the resulting JSON to excute from VBA. ``` vb ' TODO ``` Selenium Facade ------------------------------------------------------------------------------- Related Projects =============================================================================== Special Thanks -------------- * clsCDP derived from clsEdge : https://www.codeproject.com/Tips/5307593/Automate-Chrome-Edge-using-VBA - CPOL license copyright ChrisK23 * JsonConverter : https://github.com/VBA-tools/VBA-JSON - MIT/BSD license copyright Ryo Yokoyama * clsProcess : https://stackoverflow.com/questions/62172551/error-with-createpipe-in-vba-office-64bit - CC BY-SA 4.0 license * basUtf8FromString : https://www.di-mgt.com.au/basUtf8FromString64.bas.html - MIT copyright David Ireland DI Management Services Pty * WinHttpCommon / clsWebSocket : https://github.com/EagleAglow/vba-websocket-class - MIT copyright EagleAglow * ClipboardUtils : https://msdn.microsoft.com/en-us/library/office/ff192913.aspx?f=255&MSPPError=-2147217396 * WinWindowStyle : https://docs.microsoft.com/en-us/windows/win32/api/winuser/nf-winuser-showwindow Other Links ----------- * [Chrome Developer Protocol documentation](https://chromedevtools.github.io/devtools-protocol/) * [Playwright](https://playwright.dev/) * [Playwright-dotnet](https://github.com/microsoft/playwright-dotnet) * [Puppeteer](https://github.com/puppeteer/puppeteer) * [Puppeteer Sharp](https://www.puppeteersharp.com/) * [Selenium](https://www.selenium.dev/) * [SeleniumBasic](https://florentbr.github.io/SeleniumBasic/) * [Rod](https://github.com/go-rod/rod) * [package cdp for Go](https://github.com/mafredri/cdp)
